CFMOTO - CFORCE 520 - 2025

LIGHTER, STRONGER, SMARTER! with refinements across the board, the new-generation CFORCE 520 EPS is not only stronger and lighter but has less vibration, a tighter turning circle, is more comfortable and has a smorgasbord of user-friendly attributes such as electronic power steering.
NUMBERS GAME CFMOTO has left no stone unturned, and the results are compelling:
Stronger than ever with a 612kg towing capacity; 25 per cent tighter turning radius, now down to 5.6 metres one-up; 50 per cent more front and rear rack loading capacity; 30 per cent stronger and 10 per cent lighter frame; 26 per cent more suspension travel; 21 per cent more fuel capacity; 25 per cent less leg area temperature; and Reduced vibration through handlebar, footrests and seat.
WORK ASSETS CFORCE 520s work-ready attitude starts with the 28.3kW (38hp) 495cc, fuel-injected, four-stroke single-cylinder engine perfect for the farm with 2WD/4WD and a locking front differential. Other premium features: Force Red livery, alloy wheels, handguards, LED lights, five-inch LCD dash with Bluetooth connectivity, 2500lb winch, plastic racks and 25-inch tyres.
COMFORT ZONE Comfy while you do work! Ergonomic updates include a more rider-friendly handlebar position, a narrower fuel tank for more leg space but with fuel capacity still increased to 17 litres! and 40 per cent thicker seat foam to cushion your tush
TRAVEL PERKS more ground clearance (up to 254mm) and a 26 per cent increase in suspension travel now 190mm at the front and 225mm at the rear. New six-ply all-terrain tyres are grippier and sturdier. And if water crossings are your go, the air intake has also been positioned 120mm higher to reduce the fear factor!
ENGINE & TRANSMISSION
Engine type:Four-stroke single-cylinder
Displacement:495cc
Maximum power:38hp (28.3kW) at 7,000rpm
Maximum torque:39Nm at 5,750rpm
Fuel system:Bosch EFI
Transmission:CVT
Drive:H-L-N-R-Park
4WD:2WD/4WD with locking front differential
Rear differential:Fixed
Steering:Power
