CFMOTO - UFORCE - 800 XL - 2025

Introducing a new middleweight XL model to the range, the UFORCE 800 EPS XL.

Based on the popular UFORCE 600 platform, the chassis has been extended and beefed up including new suspension, steering components and greater ground clearance to accommodate the longer wheelbase. The result is a new mid-sized 4-seater UTV powered by CFMOTOs 800cc V-twin engine and featuring an all-new CFMOTO CVT system smoother driving, easier working.

Low-Speed Smoothness:
CFMOTOs CVT System provides an ultra-smooth driving experience at low speeds.

Optimised Slider Design:
Steel sliders are used instead of nylon sliders, significantly reducing the impact of temperature variations on performance and longevity.

Efficient Temperature Regulation:
The CVT maintains an optimal internal temperature, tailored specifically for a Gross Vehicle Weight of 1.7 tons, outperforming competitors with internal temperatures kept below 95C.

ENGINE
Engine type: V-twin, liquid cooled, 4-stroke, SOHC, 8-valve
Displacement: 800cc
Maximum power: 63hp at 7,000rpm
Maximum torque: 69.8Nm at 5,500rpm
Fuel system: Bosch EFI with two power modes NORMAL or WORK
Transmission: CFMOTO CVT
Drive: H-L-N-R-Park
4WD: 2WD/4WD
Differential: Fixed rear differential
Downhill Assist: Electronic assist hill descent control (DAC)
Steering: Power steering (EPS)

CHASSIS
Suspension front: Dual A-arm, with 225mm of travel
Suspension rear: Dual A-arm, with 225mm of travel
Shock absorber: Shock absorbers with compression/rebound adjustment
Brakes: All four hydraulic disc brakes
Wheels: 14-inch alloy rims
Tyres: 27-inch tyres

SIZE
Dimensions (L/W/H): 3640 x 1525 x 2007mm
Cargo tray (D/W/H): 870 x 1300 x 275mm
Wheelbase: 2770mm
Ground clearance: 300mm
Wet weight: 775kg

LOAD
Towing capacity: 680kg
Cargo tray capacity: 300kg
Roll Cage: ROPS-certified
Fuel Capacity: 40L
Persons: Four

OTHER
Winch:4500lb with nylon rope
Warranty: Two Year Warranty
